Taskmaster F1f5103n Wiring Diagram

Heaters shall be designed for a single circuit with elements motor and control circuits wired in accordance with latest national electric code and ul inc.
Taskmaster f1f5103n wiring diagram. 5100 series horizontal or vertical mounted fan forced unit heater standard taskmaster models series notes international models double eagle promo heater warning. List 686334 692694 a5105 3 3 kw to 5 0 kw 9 lbs. Mounting brackets upc model model size wt. 5100 series horizontal or vertical mounted fan forced unit heater diffuser options mounting brackets model designator not actual colors.
Unit accessory wiring diagram connect the power supply electrical ground and accessories to the correct terminals or termination points using accepted practices. All three phase heat ers have balanced phases. Markel raywall fostoria 5100 series electric unit heater 208 volt 1 phase 3 3 kw 208v control voltage 17 75 h x 14 469 w x 6 5 d catalog. Limit controls all heaters have built in fan purge to dissipate residual heat from elements on heater shutdown.
96 692700 a5120 7 5 kw to 20 0 kw 13 lbs. 25 50kw models are wired for single or two stage heating and have two speed motors. Net junction box volume kw cubic inches cc 3 3 5 74 4 1219 7 5 10 198 3245 15 0 20 198 3245 25 0 50 341 5592 installation instructions taskmaster 5100 series unit heater 4. This product can expose you to chemicals including nickel which is known to the state of california to cause cancer and chromium which is known to the state.
Red yellow shading is for diagram clarity only.
